UN32S4CKR is a new-in-box Inverter Duty Motor from US Motors / Nidec. Designed for variable-frequency-drive powered pumps, fans, and machinery.
Specifications
| Horsepower | 1 1/2 HP |
|---|---|
| Nominal RPM | 900 RPM |
| Rated RPM | 865 RPM |
| Voltage | 460 V |
| Phase | Three Phase |
| Frequency | 60 Hz |
| Electrical Type | Three Phase |
| Full-Load Amps | 3.8 A |
| Service Factor | 1.25 |
| Ambient Rating | 40 °C |
| Insulation Class | F |
| Efficiency | 72 % |
| Speed Count | 1 |
| Frame | 184TCH |
| Enclosure | TENV |
| Mounting | C-Face / Footless |
| Shaft Details | Manufacturer shaft code TCH |
| Rotation | Reversible |
| Bearings | 6206-2RS-J/C3 / 6205-2RS-J/C3 |
| Material | Rolled Steel |
| Ship Weight | 60 lb |
| Country of Origin | MEX |
