Marathon
GT4104A Marathon Pump Motor - 1.5 HP - 1750 RPM - 208-230/460 V - Drip Proof
GT4104A Marathon Pump Motor - 1.5 HP - 1750 RPM - 208-230/460 V - Drip Proof
Regular price
$472.95 USD
Regular price
Sale price
$472.95 USD
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
GT4104A is a new-in-box Pump Motor from Marathon. Designed for pump applications.
Identifiers
| Manufacturer Catalog Number | GT4104A |
|---|---|
| Manufacturer Model | 145TTDBD6044 |
| Stu's / Vendor SKU | MGT4104 |
Specifications
| Horsepower | 1.5 HP |
|---|---|
| kW | 1.1 kW |
| Rated RPM | 1750 RPM |
| Voltage | 208-230/460 V |
| Phase | Three Phase |
| Frequency | 60 Hz |
| Electrical Type | Squirrel Cage Inverter Rated |
| Full-Load Amps | 4.6-4.4/2.2 A |
| Service Factor | 1.15 |
| Overload Protection | No Protection |
| Duty Rating | Continuous |
| Ambient Rating | 40 °C |
| Insulation Class | F |
| Efficiency | 86.5 % |
| Speed Count | 1 |
| Frame | 145JMV |
| Enclosure | Drip Proof |
| Mounting | F1/F2 CAPABLE |
| Shaft Configuration | JM |
| Shaft Details | Diameter 0.874 in |
| Rotation | Reversible |
| Bearings | Ball / Ball |
| Material | Rolled Steel |
Technical values shown here are limited to manufacturer-verified data carried in the governed Marathon product record. Unverified optional fields are omitted rather than labeled unavailable.
