• FD1PM2DZYR US Motors / Nidec Auger Duty Motor - 1 HP - 1800 RPM - 190/380 & 208-230/460 V - TEFC
1 2

US Motors / Nidec

FD1PM2DZYR US Motors / Nidec Auger Duty Motor - 1 HP - 1800 RPM - 190/380 & 208-230/460 V - TEFC

FD1PM2DZYR US Motors / Nidec Auger Duty Motor - 1 HP - 1800 RPM - 190/380 & 208-230/460 V - TEFC

$471.95 USD
$471.95 USD
Sale Sold out
Shipping calculated at checkout.

FD1PM2DZYR is a new-in-box Auger Duty Motor from US Motors / Nidec. Designed for agriculture augers.

Specifications

Horsepower 1 HP
Nominal RPM 1800 RPM
Rated RPM 1800 RPM
Voltage 190/380 & 208-230/460 V
Phase Three Phase
Frequency 50/60 Hz
Electrical Type Three Phase
Full-Load Amps 3.5/1.8 & 3.3-3.2/1.5 A
Service Factor 1.15
Overload Protection Manual reset thermal overload protector
Duty Rating Continuous duty
Insulation Class B
Speed Count 1
Frame 56Y
Enclosure TEFC
Mounting Footless auger-duty mount
Shaft Configuration Keyed auger shaft with opposite-drive-end hand-crank extension
Rotation Reversible
Bearings Ball bearings
Material Rolled Steel
Motor Diameter 6.5 in
C Dimension 13 in
Length 13 in
Ship Weight 36 lb
Country of Origin MEX
