US Motors / Nidec
FD12SA2D US Motors / Nidec Farm Duty Fan Motor - 1/2 HP - 1800 RPM - 208-230/460 V - TEAO
FD12SA2D US Motors / Nidec Farm Duty Fan Motor - 1/2 HP - 1800 RPM - 208-230/460 V - TEAO
Regular price
$318.95 USD
Regular price
Sale price
$318.95 USD
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
FD12SA2D is a new-in-box Farm Duty Fan Motor from US Motors / Nidec. Designed for agriculture ventilation fans and hatcher/setter equipment.
Specifications
| Horsepower | 1/2 HP |
|---|---|
| Nominal RPM | 1800 RPM |
| Rated RPM | 1800 RPM |
| Voltage | 208-230/460 V |
| Phase | Three Phase |
| Frequency | 50/60 Hz |
| Electrical Type | Three Phase |
| Full-Load Amps | 1.8-1.8/0.9 A |
| Service Factor | 1.15 |
| Overload Protection | Automatic reset thermal overload protector |
| Duty Rating | Continuous air-over duty |
| Ambient Rating | 40 °C |
| Insulation Class | B |
| Speed Count | 1 |
| Frame | 56H |
| Enclosure | TEAO |
| Mounting | Rigid-base agri-duty fan mount |
| Rotation | Reversible |
| Bearings | Ball bearings |
| Material | Rolled Steel |
| Motor Diameter | 6.5 in |
| C Dimension | 10.9 in |
| Length | 10.9 in |
| Ship Weight | 17 lb |
| Country of Origin | MEX |
