FD12BA2P9 US Motors / Nidec Farm Duty Fan Motor - 1/2 HP - 1725 RPM - 115/230 V - TEAO
FD12BA2P9 US Motors / Nidec Farm Duty Fan Motor - 1/2 HP - 1725 RPM - 115/230 V - TEAO
Regular price
$290.95 USD
Regular price
Sale price
$290.95 USD
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
FD12BA2P9 is a new-in-box Farm Duty Fan Motor from US Motors / Nidec. Designed for agricultural direct-drive and ventilation fans in poultry and livestock houses.
Specifications
| Horsepower | 1/2 HP |
|---|---|
| Nominal RPM | 1800 RPM |
| Rated RPM | 1725 RPM |
| Voltage | 115/230 V |
| Phase | Single Phase |
| Frequency | 60 Hz |
| Electrical Type | Split Phase |
| Full-Load Amps | 5.4/2.7 A |
| Service Factor | 1.25 |
| Overload Protection | Automatic reset |
| Duty Rating | Continuous |
| Ambient Rating | 40 °C |
| Insulation Class | B |
| Efficiency | 77.7 % |
| Hazardous Location Rating | Not applicable |
| Speed Count | 1 |
| Frame | 56 |
| Enclosure | TEAO |
| Mounting | Resilient / cradle base |
| Shaft Configuration | Y |
| Shaft Details | 5/8 in diameter x 1-7/8 in keyed shaft |
| Rotation | Reversible |
| Bearings | 6203 ball bearing, both ends |
| Material | Rolled Steel |
| Motor Diameter | 6.5 in |
| C Dimension | 12.3 in |
| Ship Weight | 32 lb |
| Country of Origin | MEX |
