EU0332 US Motors / Nidec Commercial Pump Motor - 1/3 HP - 3450 RPM - 115/208-230 V - ODP
EU0332 US Motors / Nidec Commercial Pump Motor - 1/3 HP - 3450 RPM - 115/208-230 V - ODP
Regular price
$280.95 USD
Regular price
Sale price
$280.95 USD
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
EU0332 is a new-in-box Commercial Pump Motor from US Motors / Nidec. Designed for commercial pump service requiring a J-face pump motor.
Specifications
| Horsepower | 1/3 HP |
|---|---|
| Nominal RPM | 3600 RPM |
| Rated RPM | 3450 RPM |
| Voltage | 115/208-230 V |
| Phase | Single Phase |
| Frequency | 60/50 Hz |
| Electrical Type | Capacitor Start |
| Full-Load Amps | 6.2/2.9-3.1 A |
| Service Factor | Not available from manufacturer |
| Overload Protection | Automatic reset |
| Duty Rating | Not available from manufacturer |
| Ambient Rating | 40 °C |
| Insulation Class | B |
| Efficiency | Not available from manufacturer |
| Hazardous Location Rating | Not applicable |
| Speed Count | 1 |
| Frame | 56J |
| Enclosure | ODP |
| Mounting | J-face |
| Shaft Details | Manufacturer shaft code J |
| Rotation | CCW viewed from drive end |
| Bearings | DE 6203; ODE 6203 |
| Material | Rolled Steel |
| Motor Diameter | 6.5 in |
| Ship Weight | 18 lb |
| Country of Origin | MEX |
