D12ARM2N9 US Motors / Nidec Reversing Motor - 1/2 HP - 1625 RPM - 115 V - ODP
D12ARM2N9 US Motors / Nidec Reversing Motor - 1/2 HP - 1625 RPM - 115 V - ODP
Regular price
$698.95 USD
Regular price
Sale price
$698.95 USD
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
D12ARM2N9 is a new-in-box Reversing Motor from US Motors / Nidec. Designed for applications requiring rapid motor reversal.
Specifications
| Horsepower | 1/2 HP |
|---|---|
| Nominal RPM | 1800 RPM |
| Rated RPM | 1625 RPM |
| Voltage | 115 V |
| Phase | Single Phase |
| Frequency | 50/60 Hz |
| Electrical Type | PSC |
| Full-Load Amps | 5.0/5.7 A |
| Service Factor | 1 |
| Overload Protection | Manual Reset |
| Ambient Rating | 25 °C |
| Insulation Class | B |
| Speed Count | 1 |
| Frame | 56 |
| Enclosure | ODP |
| Mounting | Resilient Base |
| Shaft Details | Manufacturer shaft code Y |
| Rotation | Reversible |
| Bearings | 6203 / 6203 |
| Material | Rolled Steel |
| Motor Diameter | 6.5 in |
| Ship Weight | 20 lb |
| Country of Origin | MEX |
