US Motors / Nidec
9721 US Motors / Nidec Refrigeration Motor - 1/12-1/20 HP - 1550 RPM - 115/208-230 V - OAO
9721 US Motors / Nidec Refrigeration Motor - 1/12-1/20 HP - 1550 RPM - 115/208-230 V - OAO
Regular price
$101.95 USD
Regular price
Sale price
$101.95 USD
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
9721 is a Refrigeration Motor from US Motors / Nidec.
Application: Refrigeration applications
Specifications
| Horsepower | 1/12-1/20 HP |
|---|---|
| Nominal RPM | 1800 RPM |
| Rated RPM | 1550 RPM |
| Voltage | 115/208-230 V |
| Phase | Single Phase |
| Frequency | 50/60 Hz |
| Electrical Type | PSC |
| Full-Load Amps | 1.1/0.57 A |
| Service Factor | 1 |
| Overload Protection | Automatic Reset |
| Ambient Rating | 50 |
| Insulation Class | B |
| Speed Count | 1 |
| Frame | 33 |
| Enclosure | OAO |
| Mounting | Stud |
| Rotation | CCWSE REV |
| Bearings | Ball |
| Material | Rolled Steel |
| Motor Diameter | 3.3 in |
| Length | 8.81 in |
| Width | 5.88 in |
| Height | 5.81 in |
| Ship Weight | 4 lb |
| Country of Origin | China |
New in box.
